User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-39-
Figure 5-7 Gateway – Wireless
The page includes the following fields:
Object Description
Wi-Fi Status Select ON (Green) or OFF (Gray) to enable or disable wireless LAN
SSID
It is the wireless network name. The default SSID is PLANET_2.4G
and PLANET_5G
Hide your SSID Select ON (Green) or OFF (Gray) to hide wireless LAN or not
Channel
Select the operating channel you would like to use. The channel
range will be changed by selecting a different domain.
Encryption Select the wireless encryption. The default is None
Timing
Set time to restart for clock
To Next Page
