User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-42-
Figure 5-10 Super WDS Mode – 5G SSID
The page includes the following fields:
Object Description
Wi-Fi Status Select ON (Green) or OFF (Gray) to enable or disable wireless LAN
SSID
It is the wireless network name. The default SSID is “PLANET_5G”
Hide your SSID Select ON (Green) or OFF (Gray) to hide wireless LAN or not
Bandwidth Select the operating channel width, “20MHz” or “40MHz” or
“80MHz”
Channel
Select the operating channel you would like to use. The channel
range will be changed by selecting a different domain.
Encrypt Select the wireless encryption. The default is “None”
