User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-57-
Figure 5-28 AP Mode – Set up Wi-Fi
The page includes the following fields:
Object Description
Wi-Fi Status Select ON (Green) or OFF (Gray) to enable or disable wireless LAN.
SSID
It is the wireless network name. The default SSID is “PLANET_5G”.
Hide your SSID
Select ON (Green) or OFF (Gray) to hide wireless LAN or not.
Bandwidth Select the operating channel width, “20MHz” or “40MHz” or
“80MHz”.
Channel
Select the operating channel you would like to use. The channel
range will be changed by selecting a different domain.
Encryption Select the wireless encryption. The default is “None”.
Timing
Set time to restart.
