User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-67-
Figure 5-39 PPPoE (ADSL)
The page includes the following fields:
Object Description
Username
Enter the PPPoE User Name provided by your ISP.
Password
Enter the PPPoE password provided by your ISP.
Server Name
Enter the server description or not.
Service Name
Enter the service description or not.
MTU
Maximum Transmission Unit. Default is 1452.
Set DNS Manually
Enable/Disable DNS Manually.
Primary DNS
Enter the necessary DNS address provided by your ISP.
Secondary DNS
Enter the secondary DNS address provided by your ISP.
Band Type
Select the band type provided by your ISP.
Upstream
Enter limited upstream throughput, default is 1000000 Kbps.
Downstream
Enter limited downstream throughput, default is 1000000 Kbps.
DHCP
Choose “DHCP” and the router will automatically obtain IP addresses, subnet masks and gateway addresses
from your ISP.
