User Manual of WDAP-C7210E_WDAP-W1200E_WDAP-850AC
-73-
Figure 5-46 MAC Filtering
The page includes the following fields:
Object Description
Add Press the “Add” button to add the rule in the black or white list
Delete Press the “Delete” button to delete the rule
Apply Press the “Apply” button to enable/disable the rule
Status
Select ON (Green) or OFF (Gray) to enable or disable
Rule Name
Enter the rule name, e.g. Black list
Time Group
Select Any or Customer to set up time range and work data.
MAC Address
Enter the MAC address that you need to put in black or white list
Mark
Enter the mark string, or not
MAC Filtering Status Select the rule of MAC Filtering, default is Disable.
Whitelist: Allow the devices to pass in the rule
Blacklist: Prohibited rules within the device through
