Chapter E - DIMAX3 DIGITAL SYSTEM ADJUSTMENT
Planmeca Proline CC panoramic x-ray E-67
Technical Manual
The frame cover fastening flat spring must be on the same level as the trail holder (see figure
below, 1). If needed, loosen the attachment screws (2) and move the fastening flat spring.
Tighten the attachment screws.
Figure 116
Attach the frame cover.
1
2
