Chapter H - PARTS REPLACEMENT & REPAIR
H-2 Planmeca Proline CC panoramic x-ray
Technical Manual
1.4 Rotating arm cover
Remove the front cover of the tube head.
Remove the cover of the secondary slot.
Push the cover to the shown direction (arrow 1) all the way to the groove. Remove one end of the
cover pulling to the shown direction (arrow 2). To remove the other end, keep it in this angle as it
falls only to the collimator.
1.5 Lower shelf cover
a) Drive the head support to open position.
b) Drive the positioning mechanism to outmost position).
c) Remove the chin rest adaptor.
d) Remove the fixing screws under the lower shelf.
e) Remove the cover lifting up and turning counter clockwise.
1.6 Z-carriage cover
a) Remove the cover of the lower shelf.
b) Remove the connectors
c) Remove the lower shelf.
d) Remove the cover.
1.7 Upper shelf cover
a) Remove the rotating part.
b) Remove the connectors of the sagittal light.
c) Remove the fixing screws of the cover.
d) Remove the cover.
