Planmeca Proline CC - 9 CEPHALOSTAT ADJUSTMENT; 9.1 Removing the cassette holder cover

Chapter D - ADJUSTMENT & CALIBRATION
Planmeca Proline CC panoramic x-ray D-33
Technical Manual
9 CEPHALOSTAT ADJUSTMENT
9.1 Removing the cassette holder cover
Loosen the two M4x8 BN 5950 bolts on the top of the cover with a 5.5 mm ring spanner. Loosen
the two M4x4 DIN 7985 screws on the bottom of the cover. Pull the cover away from the cassette
holder.
RemCephCover2.eps
M4x8 BN 5950
M4x4 DIN 7985
