Planmeca Proline CC panoramic x-ray C-1
Chapter
Technical Manual
C HELP & ERROR MESSAGES
1 HELP MESSAGES
The following is a list of the help messages. These messages appear on the main display if a key
is pressed that has no function, or if the function is not allowed for some reason. The help mes
-
sage disappear automatically when you release the key.
HELP CODE HELP MESSAGE EXPLANATION
HE 0
The key has no function in this mode.
HE 1
The key has no function with the control key.
HE 2
The error code must first be cleared from the display by pressing the control key.
HE 3
The unit must be driven to the ready position with the special program keys (in
Transversal slicing system mode).
HE 4
The patient positioning mechanism can be moved only in the manual transversal
slicing system mode.
HE 5
You are using a wrong secondary slot. Select an other slot.
HE 6
The temple support motor has been inactivated. The temple support movement
does not operate.
HE 7
The X-ray unit is not equipped with a Cephalostat.
HE 8
You can not change the horizontal segment, there is only one primary slot in the
panoramic mode.
In Transversal slicing system mode the primary slot is selected automatically.
HE 9
The soft tissue filter can not be moved when taking a posterior-anterior or ante-
rior-posterior exposure.
HE 10
The X-ray unit is busy, wait until the previous function is completed.
HE 15
The x-ray unit is not communicating with the PC, e.g. the Dimaxis software is not
running.
HE 16
The patient is not selected in the Dimaxis software.
HE 17
The sensor head is not in its position.
HE 18
In the cephalometric mode there is also a sensor head in the rotating unit in addi-
tion to the sensor head attached to the cephalostat. Remove the sensor head
from the rotating unit.
HE 19
The unit exposure mode (panoramic/cephalometric) differs from the mode
selected in the Dimaxis software.
