Planmeca Proline CC - Page 45

Chapter D - ADJUSTMENT & CALIBRATION
Planmeca Proline CC panoramic x-ray D-3
Technical Manual
Cephalometric mode calibration
• Cephalometric beam alignment tool (18x24 cm, part number 652232; 8x10 in, part number
652233).
Used to check the position of the cephalometric x-ray beam.
• Soft tissue filter positioning tool (part number 653121).
• Ceph head support alignment tools (part number 653126). The part number includes two
pieces.
P
L
A
N
M
E
C
A
P
M
200
2 P
ro
lin
e
C
e
p
h
alo
s
ta
t 1
8
x24
N
o
. 6
522
3
2
Soft tissue filter 0mm
Positioning light 0mm
Positioning light 25mm
4
5
6
Cephalometric beam alignment tool
Soft tissue positioning tool
Ceph head support alignment tools
