Planmeca ProOne - Understanding the Exposure Switch Operation

14
Loosen the 2.5mm allen screw on the bottom of Sensor Head cover then pull the
cover off. (Figure 16)
Figure 16
3 Inner Tubehead
Loosen the 2.5mm allen screw on the bottom of the Tubehead cover then pull the
cover off. (Figure 17)
Figure 17
Printed copies of this document are considered uncontrolled.
7535.11.Rev001 08.07.2018
