Planmeca ProOne - Table of Contents

3
Table of Contents
Chapter A: General Information
1. Disclaimer 5
2. Required Tools 7
2.1 Calibration Tools 7
2.2 Hand Tools 8
Chapter B: Pre-check
1. Dimaxis 4.3.x 9
2. Ball Phantom Test 9
2.1 Measurement Tool Calibration 10
2.2 Measuring Image 10
Chapter C: Removing Covers
1. Upper Arm 13
2. Sensor Head 13
3. Inner Tubehead 14
4. Inner C-Arm 15
Chapter D: Alignment
1. Beam Adjustment 17
1.1 Vertical Alignment 19
1.1.a. High/Low 19
1.1.b Angled 19
1.2 Horizontal Alignment 20
1.2.a Left/Right 20
2. Ball Phantom y-line 21
2.1 Adjusting Y-line 23
3. Ball Phantom x-line 24
3.1 Adjusting X-line 26
3.2 Checking the symmetry 27
3.2.a More than 1mm deviation 28
4. Positioning Lights 29
4.1 Layer 29
4.1.a Adjusting the light 31
4.2 Midsagittal 32
4.3 Frankfort 32
4.3.a Adjusting the light 33
Chapter E: Calibrating the sensor
1. ProOne Setup 35
2
. Computer Setup 36
3. Calibration File creation 37
Printed copies of this document are considered uncontrolled.
7535.11.Rev001 08.07.2018
