8
Alignment Ruler (part number 50973) used for checking
the alignment
of the patient positioning mechanism. (Figure 4)
Figure 4
Calibration block (part number 10016995) used for calibrating the
sensor. (Figure 5)
Figure 5
Alignment Pins (part number 7100) used for locking th
e c-arm into
positioning for checking alignment. (Figure 6)
Figure 6
2.2 Hand Tools
2.5 mm allen wrench
4 mm allen wrench
Needle Nose Pliers
Printed copies of this document are considered uncontrolled.
7535.11.Rev001 08.07.2018
