11 Technical data
11.1 Reference conditions
Condition Unit Value
Compressed air effective inlet pressure barg 7
psig 101.5
Compressed air inlet temperature ˚C 35
˚F 95
Relative humidity of the air at inlet % 100
Pressure dew point (PDP —20 °C version) °C -20
°F -4
Pressure dew point (PDP —40 °C version) ˚C -40
˚F -40
11.2 Limitations for operation
Limitation Unit Value
Maximum compressed air effective inlet pressure barg 14
Maximum compressed air effective inlet pressure psig 203
Minimum compressed air effective inlet pressure barg 4
Minimum compressed air effective inlet pressure psig 58
Maximum ambient air temperature ˚C 45
Maximum ambient air temperature ˚F 113
Minimum ambient air temperature ˚C 1
Minimum ambient air temperature ˚F 34
Maximum compressed air inlet temperature ˚C 50
Maximum compressed air inlet temperature ˚F 122
Minimum compressed air inlet temperature ˚C 2
Minimum compressed air inlet temperature ˚F 36
Minimum volume flow at inlet See Dryer data.
11.3 Dryer data
Standard version, PDP -20 °C
PH 55 PH 75 PH 95 PH 120 PH 140 PH 190
Volume flow at
dryer inlet
l/s 25 35 45 55 65 90
