When the Chart (Low Resolution) is selected, a chart showing the parameter per day is shown on
the main screen. Each point is the average of 1 hour. The screen shows 10 days.
The switch button (icon) for selecting other screens is changed into a small chart and is
highlighted (active).
5.5 Calling up menus
When the voltage is switched on, the main screen is shown automatically (see section Main
screen):
(1) Pressure equalization
(2) Menu
• To go to the Menu screen, highlight the Menu button (2), using the Scroll keys.
• Press the Enter key to select the menu. Following screen appears:
• The screen shows a number of icons. Each icon indicates a menu item. By default, the
Inputs icon is selected. The status bar shows the name of the menu that corresponds with
the selected icon.
• Use the Scroll keys to select an icon.
• Press the Enter key (2) to open the menu or press the Escape key (3) to return to the Main
screen.
Instruction book
32 2920 7111 23
