14 Pressure Equipment Directives
Components Subject to Pressure Equipment Directive (PED) 2014/68/EU
Parts of article 4.3 of 2014/68/EU are subject to Sound Engineering Practice (SEP).
Parts of category I according to 2014/68/EU are integrated into the machine and fall under the
exclusion of article I, section 2-(f)-(i).
The table below contains the necessary information for the inspection of all category I pressure
equipment according to Pressure Equipment Directive (PED) 2014/68/EU.
Tube drawing
p.n.
Design
pressure
bar(e)
Design
temperature
°C
PED
category
Tube wall
thickness
mm
Tube
diameter
mm
Tube
internal
volume
l
1627 6307 91 14 -10 to +66 I 5 150 9.8
1627 6307 92 14 -10 to +66 I 5 150 10.5
1627 6307 93 14 -10 to +66 I 5 150 13.6
1627 6307 94 14 -10 to +66 I 5 150 16.8
1627 6307 95 14 -10 to +66 I 5 150 19.5
1627 6307 96 14 -10 to +66 I 5 150 24.7
Recommendation of the manufacturer for inspection intervals
Following actions are to be executed by authorized service personnel only, unless stated
otherwise in the applicable legislation. The stated time interval takes the start-up day of the unit
as reference.
• Every 6 months: inspect the vessel material on the outside (exposed) for traces of strong
corrosion. Consult the service department of your supplier if necessary.
• Every 5 years: when replacing the desiccant, following inspections are to be carried out:
• Inspection of outside and inside of the material for excessive and local corrosion.
• Inspection of outside and inside of the material for fissures, leaks, and damage.
Consult the service department of your supplier if necessary.
• Hydrostatic test according to the Pressure Equipment Directive (PED) 2014/68/EU when
required by local regulations. Consult the service department of your supplier if necessary.
Instruction book
88 2920 7111 23
