Polaris 800 RMK ASSAULT 2011

7.17
Shocks
7
2013 Rear Track Shocks (RTS)
SHOCK PN MODEL
EXTENDED
LENGTH
IN
COLLAPSED
LENGTH
IN
STROKE
IN
SHOCK
ROD
IN
IFP
DEPTH
IN
OIL
VOLUME PSI
7043177 FOX™ 15.60 10.56 5.04 .50 1.22
Full 200
7043723
Walker Evans
™
17.25 12.0 5.25 .625 2.0
7043635 16.71 10.96 5.75 .50 2.25
7043629 16.80 11.35 5.45 .625 2.0
7043862 FOX™ 17.29 12.06 5.23 .498 2.26
7043834 Walker Evans
™ 16.80 11.35 5.45 .625 6.25
2013 Rear Track Shocks
SHOCK 7043177 7043723 7043635 7043629 7043862 7043834
REBOUND
.620 x .093
.800 x .012
.900 x .012
1.0 x .012
1.10 x .012
1.25 x .010
1.25 x .010
.625x.065
.7
00x.012
.800x.012
.900x.012
1.0x.012
1.10x.012
1.20x.012
1.25x.015
1.25x.015
.625x.065
.7
00x.010
.800x.010
.900x.010
1.00x.012
1.10x.012
1.25x.015
1.25x.015
1.25x.015
.625x.065
.7
00x.015
.800x.015
.900x.015
1.00x.015
1.10x.015
1.20x.012
1.25x.015
1.25x.015
.620 x .093
.700
x .012
.800 x .012
.900 x .012
1.0 x .012
1.10 x .015
1.250 x .015
1.250 x .015
.875 x .090
.7
00 x .008
.800 x .015
.900 x .012
1.0 x .010
1.10 x .010
1.20 x .010
1.25 x .008
Piston
O
rifice
.093 .055 .086 N/A .093 .069
Shaft
Bl
eed
N/A .086 N/A .082 N/A N/A
COMPRESSION
1.3 x .008
1.3 x .008
1.0 x .006
1.10 x .008
1.10 x .010
1.10 x .012
1.0 x .010
.900 x .010
1.125 x .093
1.30x.006
1.25
x.006
.900x.010
1.30x.008
1.20x.008
1.10x.008
.800x.008
1.20x.008
1.0x.006
.900x.006
.800x.006
.700x.006
.875.090
1.30x.008
1.25x.00
6
.800x.012
1.25x.010
1.10x.010
1.00x.010
.900x.010
.800x.010
.700x.010
.625x.065
1.30x.010
1.20x.00
8
1.00x.010
1.25x.012
1.20x.008
1.10x.008
1.00x.008
.900x.008
.800x.008
.700x.008
.875x.065
1.30 x .006
.700
x .012
1.250 x .008
1.10 x .008
1.0 x .006
.900 x .006
.800 x .006
.700 x .006
.620 x .020
1.125 x .093
1.30 x .008
1.10
x .010
.900 x .008
1.30 x .010
1.20 x .010
1.10 x .010
1.0 x .010
.900 x .010
.800 x .010
.700 x .008
.875 x .090
ADJUSTER
N/A
Rebound
.8
00x.012
Compression
1.0x.025
1.0x.025
.900x.015
.625x.065
1.10x.025
1.10x.02
5
1.00x.025
.875x.090
Rebound
1.00x.02
5
1.00x.025
.625x.065
N/A N/A
