8.4
Steering and Suspensions
Front Suspension Type by Model
Rear Suspension Type by Model
Camber / Toe Specifications
Maximum width and camber measurements are achieved
with the front end elevated and shocks at full extension.
Toe alignment is measured at ride height. This means that
th
e machine is on the ground and resting at normal ride
height, not full rebound. Measure at a point 10” (25.4cm)
forward of the ski mount bolt and 10” (25.4cm) behind the
ski mount bolt, preferably on the center line of the carbide
skags.
Maximum width is measured from the center of the
s
pindles unless noted otherwise.
Camber measurement is taken from the top of the
align
ment bar to the top of the ski mount hole in the spindle
with the bushing removed.
NOTE: Only models featuring upper control arms
w
ith rod ends allow camber adjustments.
FRONT SUSPENSION MODELS
Pro-Ride
2010-2011Rush/
Switchback Assault
Pro-Ride (Fixed Camber)
2012-2013
Rush/Switchback/
Swit
chback Assault
600 INDY
Pro-Ride RMK Adjustable RMK/Pro RMK
Pro-Ride Wide Adjustable RMK Assault
REAR SUSPENSION MODEL
Pro-Ride Progressive 120 2010 Rush
Pro-Ride Progressive 121 Rush
Pro-Ride Progressive 136 Switchback
Switchback 144 Switchback Assault
RMK Coil Over 155/163
RMK/Pro RMK/RMK
Assault
INDY 121 600 INDY
Camber & Toe Specifications
SUSPENSION
MAXIMUM
SET UP
WIDTH in/cm
(± .25in
/
.6cm)
CAMBER
in
/cm
TOE OUT
(At ride
height)
in/cm
Pro-Ride
41.52/105
1.68 ± .31
(4
.2 ± 0.8)
0 -.12
(0
-0.305)
Pro-Ride
(F
ixed
Camber)
N/A
Pro-Ride RMK
Adjustable
2011-2012
2013
(Measured
in
side of
spindles)
36.26/92
36.85
/93.6
1.95 0.31
(4.3 0.
8)
Pro-Ride Wide
Adjust
able
38.58/98 2.25 0.31
(5.7 0.8)
