General Information
1
NOTE: * = Rider weight in everyday clothing.
** = From full soft (CCW) position.
General
Width (in/cm) 48 / 121.9
Length (in/cm) 108 / 274
Height (in/cm) 46 / 117
Estimated Dry Weight (lb/kg) 469 / 212
Fuel (Gallons / Liters) 11 / 41.6
Oil (Quarts / Liters) 3.4 / 3.3
Cooling System Capacity(Qts/ L) 6 / 5.7
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211122
1.460
/ 3.7
26°
46.77 / 118.8
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
7.53
23
39
72
Po
laris Synthetic (80W)
9 / 266
PERC
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 VDC (Total)
13.5 - 14.5 VDC
400
Ignition Timing
18° @1700 RPM
Co
olant Temp = 120° F (49° C)
Spark Plug Gap in.(mm) .027 (.70)
Spark Plug NGK BPR9ES
Front Suspension
Suspension Type PRO-RIDE
Shocks
RUSH
RUSH PRO-R
Fox HPG w/IFP
W
alker Evans Needle Piggyback
16 Click Compression Adjustable
Factory Setting** = 6
IFS Spring Rate
lbs/in (N/mm)
100 (17.5)
Spring Preload -
Inches (cm)
4.5 (11.4)
Travel-Inches (cm) 9 (22.9)
Ski Center Distance
Inches (cm)
Setup Width
42.5 (108)
41
.52 (105)
Camber Inches (cm) 1.68 0.31 (4.3 .8
)
Toe Out Inches (mm) 0 -1/8 (0
- 3)
Rear Suspension
Suspension Type PRO-RIDE Progressive
Front Track Shock
(FTS)
RUSH
RUSH PRO-R
Fox HPG w/IFP
W
alker Evans w/Remote Reservoir
16 Click Compression Adjustable
Factory Setting** = 2
FTS Spring Rate
lbs/in (N/mm)
120 - 310 (21 - 54.25)
FTS Spring Installed
L
ength-Inches (cm)
RUSH Preload
RUSH PRO-R Preload
7.5 (19.05)
1.0 (2.54)
1.0 (2.54)
Rear Track Shock
(RTS)
RUSH
RUSH PRO-R
Fox HPG w/IFP
W
alker Evans Needle
w/Remote Reservoir
16 Click Compression Adjustable
Factory Setting** = 4
Standard RTS Spring
Rider Weight*
120 - 250lbs.
Rate lbs/in (N/mm)
PN: 7043572-133
1
90 (33.25)
LW RTS Spring
Rider Weight*
90 - 150lbs.
Rate lbs/in (N/mm)
PN: 7041575-385
120
(21)
HD RTS Spring
Rider Weight*
240 - 335+lbs.
Rate lbs/in. (N/mm)
PN: 7043585-385
2
60 (45.5)
RTS Spring
Rider / Weight Setting
Spring length set to rider weight
using
adjustment gauge.
STD Gauge PN: 5254748
LW Gauge PN: 5254749
HD Gauge PN: 5254750
(STD gauge in tool kit. LW and HD
gauges are accessories and should
be ordered when ordering a LW or
HD spring.)
Rider weight adjustment can also be
performed using tape measure and
RTS Spring Guide Table located in
the Steering/Suspension Chapter.
Rear Travel
Inches (cm)
14 (35.6)
To Next Page
