9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
INTAKE MANIFOLD ADAPTER SERVICE
REMOVAL
CAUTION
Ensure the engine is clean and free of debris before
removing the manifold.
1. Remove the Intake Manifold. Refer to Intake Manifold
Service page 3.16.
2. Remove the four fasteners
q
securing the intake
manifold adapters
w
to the engine and remove the
adapters.
INSTALLATION
1. Inspect the gasket surface on the adapters and
replace the adapter as needed.
2. Install the intake manifold adapters
w
and secure to
the engine using the four fasteners
q
. Torque to
specification.
TORQUE
Intake Manifold Adapter Fasteners:
7 ft-lbs (10 Nm)
3. Install the Intake Manifold. Refer to Intake Manifold
Service page 3.16.
ENGINE / COOLING / EXHAUST
