3.52
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
4. Install the three M8 oil sump fasteners
q
and torque
to specification.
TORQUE
Oil Sump Fasteners (M6):
26 ft-lbs (35 Nm)
5. Fill the engine oil. Refer to Engine Oil Level
Inspection.
6. Install the skid plate. Refer to Skid Plate Service page
11.35.
OIL PUMP SERVICE
REMOVAL
1. Remove the oil sump. Refer to Oil Sump Service
page 3.51.
2. Remove the three fasteners
q
securing the oil pump
to the engine.
3. Remove the two dowels
w
.
ENGINE / COOLING / EXHAUST
