12
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
12.9
VEHICLE HARNESS SERVICE
CHASSIS HARNESS ROUTING
NOTICE
Engine harness routing is located in the Engine Electrical Chapter. Refer to Engine Harness Routing page 4.3.
FRONT UPPER VEHICLE ROUTING
REF DESCRIPTION
q
Terminal Block
w
Terminal Block Connector
e
Terminal Block Power Cable
r
Left Headlight Connector
t
Front Ground Connection
y
Right Headlight Connector
CHASSIS / BODY ELECTRICAL
