Polaris RANGER 1000 2021 User Manual

5.22
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
EVAP SYSTEM
CARBON CANISTER SERVICE
REMOVAL
1. Remove the driver’s rocker panel. Refer to Rocker
Panel Service page 11.41.
2. Disconnect the vent line
q
, purge line
w
and fresh
air line
e
.
3. Push the retaining tab in and lift the canister straight
up to remove from the bracket.
INSTALLATION
1. Install the canister in the vehicle and align with the
bracket guides.
2. Install the canister straight down and engage the
retaining clip.
3. Connect the vent line
q
, purge line
w
and fresh air
line
e
.
4. Install the driver’s rocker panel. Refer to Rocker
Panel Service page 11.41.
FUEL SYSTEM
