11.38

9850045 R01 - 2020-2021 RANGER 1000 Service Manual

SIDE BEZEL COVER SERVICE

REMOVAL

1. Remove the two fasteners

securing the intake

cover to the side bezel.

2. Carefully pry out the retainers

and remove the

cover towards the front of the vehicle.

INSTALLATION

1. Install the intake cover and ensure the front retention

clips

are properly seated.

2. Install the two intake cover fasteners

and torque to

specification.

TORQUE

Side Bezel Cover Fasteners:

22 in-lbs (2.5 Nm)

BODY / FRAME
