11.35
3. Install the four push rivets
w
.
4. Reinstall the upper fender.
SKID PLATE SERVICE
• Remove the thirteen fasteners and washers
q
securing the skid plate to the vehicle and remove the
skid plate.
TORQUE
Skid Plate Fasteners:
6 ft-lbs (8 Nm)
