1.12
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
PART DESCRIPTION
TORQUE SPECIFICATION
Flywheel Retaining Fastener
Step 1: Torque to 129
ft-lbs (175 Nm)
Step 2: Back out bolt
180°
Step 3: Torque to 129
ft-lbs (175 Nm)
Heater Valve Fasteners
6 ft-lbs (8 Nm)
Heat Shield Fastener
(Exhaust Pipe)
6 ft-lbs (8 Nm)
Heat Shield Fastener (Body)
42 in-lbs (5 Nm)
Intake Duct Hose Clamp 35 in-lbs (4 Nm)
Intake Manifold Adapter 7 ft-lbs (10 Nm)
Intake Manifold Boot Clamp 17 in-lbs (2 Nm)
Lower Crankcase Fastener
(M10)
Step 1: 9 ft-lb (12 Nm)
Step 2: 21 ft-lb (28 Nm)
Step 3: Tighten
additional 90°
Lower Crankcase Fastener
(M6)
9 ft-lbs (12 Nm)
Lower Crankcase Fastener
(M8)
26 ft-lbs (35 Nm)
Lower Intake Plenum
Fastener
18 ft-lbs (24 Nm)
Muffler Mount Fastener
10 ft-lbs (14 Nm)
Oil Filter Adapter 21 ft-lbs (28 Nm)
Oil Cooler Retaining
Fastener
7 lb-ft (10 Nm)
Oil Pump Mounting Fastener 7 ft-lbs (10 Nm)
Oil Pump Pick-Up Retaining
Fastener
7 ft-lbs (10 Nm)
Oil Pump Sprocket Fastener 7 ft-lbs (10 Nm)
Oil Sump Cover Fastener
(M6)
9 ft-lbs (12 Nm)
Oil Sump Cover Fastener
(M8)
26 ft-lbs (35 Nm)
One Way Clutch Retaining
Fastener
9 ft-lbs (12 Nm)
Rear Engine Mount
Fasteners
45 ft-lbs (61 Nm)
Rear Engine Mount
Fasteners (Preliminary
Torque)
5 ft-lbs (7 Nm)
PART DESCRIPTION
TORQUE SPECIFICATION
Stator Cover Fastener 9 ft-lbs (12 Nm)
Tensioner Mounting
Fastener
7 ft-lbs (10 Nm)
Thermostat Cover Fastener
7 ft-lbs (10 Nm)
Throttle Body Fasteners 7 ft-lbs (10 Nm)
Upper Crankcase Fastener
(M6)
7 ft-lbs (10 Nm)
Upper Crankcase Fastener
(M8)
26 ft-lbs (35 Nm)
Valve Cover Fastener 7 ft-lbs (10 Nm)
Water Pump Impeller
Fastener
7 ft-lbs (10 Nm)
(Apply Loctite® 204™ to
bolt threads)
Water Pump Mounting
Fastener
7 ft-lbs (10 Nm)
GENERAL INFORMATION
