1.22
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
STEERING / SUSPENSION
RANGER 1000
Steering Wheel Free-Play 0.8-1.0 in (20-25 mm)
Wheel Toe Out
0.0 in (0.0 mm) +/- 0.25 in (6.35 mm)
Front Suspension Independent Dual A-Arm
Front Travel
10.0 in (25.4 cm)
Rear Suspension Independent Dual A-Arm
Rear Travel
10.0 in (25.4 cm)
Spring Adjustment Threaded Spanner Wrench
WHEELS / BRAKES
RANGER 1000
Front Wheel Type / Size
Aluminum / 12 x 6
Rear Wheel Type / Size
Aluminum / 12 x 8
Front Tire Size / Model
BASE: 25 x 10-12 NHS; 489
LE: 26 x 9-12, PXT 2.0
Rear Tire Size / Model
BASE: 25 x 11-12; 489
LE: 26 x 11-12; PXT 2.0
Front Tire Air Pressure 10 PSI (69 kPa)
Rear Tire Air Pressure 14 PSI (96.5 kPa)
Brake System
Front & Rear
Foot Actuated 4 Wheel Hydraulic – Dual Bore Caliper
Brake Fluid DOT 4
• For clutch settings, refer to Clutch Settings page 6.2 in the PVT Chapter.
GENERAL INFORMATION
