8.6

9850045 R01 - 2020-2021 RANGER 1000 Service Manual

7. Remove the wheel hub and brake disc assembly.

8. Remove the fastener retaining the tie rod end to the

bearing carrier.

9. Remove the upper ball joint pinch bolt.

10.Remove the lower ball joint fastener.

11. Using a soft faced hammer, lightly tap the bearing

carrier while removing the upper and lower ball joints

ends from the bearing carrier.

12.Pull the bearing carrier out to remove it from the

driveshaft.

FINAL DRIVE
