9850045 R01 - 2020-2021 RANGER 1000 Service Manual

8.9

7. Install front wheel hub assembly.

8. Install washer(s).

NOTICE

If cone washers are used, ensure that the washer is

installed with the domed side facing out.

9. Install the castle nut. Torque to specification.

TORQUE

Front Hub Castle Nut:

80 lb-ft (108 Nm)

10.Install new cotter pin. If the cotter pin does not align

with the holes, tighten nut slightly to align holes for

the cotter pin.

FINAL DRIVE
