8.32

9850045 R01 - 2020-2021 RANGER 1000 Service Manual

5. Remove the spring retainer and torsion spring from

the top of the ring gear.

6. Remove the ring gear and roll cage assembly from

the gearcase housing. With the ring gear removed

inspect the ring gear dowel pin and ensure that it is

seated correctly.

7. Remove inner and outer bushing / spacer.

8. Remove the RH output hub assembly from the

gearcase housing.

9. Remove pinion seal.

FINAL DRIVE
