8
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
8.41
12.Install both front brake caliper assemblies. Torque to
specification.
TORQUE
Front Caliper Mounting Fastener:
28 ft-lbs (38 Nm)
13.Install the front bumper.
14.Install both front wheels. Torque to specification.
TORQUE
Wheel Lug Nuts:
120 ft-lbs (163 Nm)
15.Add the proper lubricant to the front gearcase. Check
drain / fill plug for proper torque. Refer to
Maintenance Chapter for fluid fill and change
information.
TORQUE
Front Gearcase Fill / Drain Plug:
10 ft-lbs (14 Nm)
FINAL DRIVE
