11.54
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
5. Remove the lower regulator fastener
r
.
6. Lift the regulator and rotate clockwise to allow the
regulator to be remove from the door.
7. Loosen the fasteners securing the glass to the
regulator to service the glass or regulator.
INSTALLATION
1. Install the glass in the window regulator and tighten
the fasteners.
TORQUE
Window Glass Fasteners:
Torque until fully seated
2. Angle the window regulator clockwise to install in the
window tracks.
3. Rotate the regulator assembly counter-clockwise
while installing straight down and align with mounting
holes.
BODY / FRAME
