9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
1.49
SPN COMPONENT
FMI CONDITION CODE
168
System Power
1 Data Valid But Below Normal Operational Range - Most Severe Level P1563
2 Data Erratic, Intermittent Or Incorrect P0561
3 Voltage Too High C1063 / P0563 / C1820
4 Voltage Too Low P0562
16 Data Valid But Above Normal Operating Range - Moderately Severe
Level
P1564
18 Data Valid But Below Normal Operating Range - Moderately Severe
Level
P1565
171
Ambient Air Temperature
19 Received Network Data In Error U25C7
173
Exhaust Temperature Sensor
0 Data Valid But Above Normal Operational Range - Most Severe Level P1517
3 Voltage Above Normal, Or Shorted To High Source P0546
4 Voltage Below Normal, Or Shorted To Low Source P0545
10 Abnormal Rate Of Change P1546
175
Oil Temperature Sensor
2 Data Erratic, Intermittent Or Incorrect P3096
12 Bad Intelligent Device Or Component P3097
190
Engine Speed
0 Data Valid But Above Normal Operational Range - Most Severe Level P0219 / C1059
1 Data Valid But Below Normal Operational Range - Most Severe Level C1060
2 Data Erratic, Intermittent Or Incorrect C1061
7 Mechanical System Not Responding Or Out Of Adjustment P1219
19 Received Engine Speed Has Error P3219 / C1066
31 Error in Engine Speed Computation P121C
400
Engine Speed
31
Error in Engine Speed Computation
P121D
523
Gear Sensor Signal
2 Data Erratic, Intermittent Or Incorrect P0914
3 Voltage Above Normal, Or Shorted To High Source P0917
4 Voltage Too Low P0916
9 Abnormal Update Rate P1914
11 Root Cause Not Known P0915
525
Transmission Requested Gear
19 Received Network Data In Error U255C
527 Cruise Control Panel Switches
31 Condition Exists P153D
563 ABS active
19 Received Network Data In Error U25C9
597 Brake Switch
2 Data Erratic, Intermittent Or Incorrect C0040
9 Abnormal Update Rate C1240
10 Abnormal Rate Of Change C2453
19 Received Network Data In Error C1340
627
System Voltage
15 Data Valid But Above Normal Operating Range - Least Severe Level P2504
17 Data Valid But Below Normal Operating Range - Least Severe Level P2503
628
ECU Memory
12 Bad Intelligent Device Or Component P1602 / C1073
13 Out Of Calibration P0601 / C1601
630 Calibration 19 Checksum/CRC Error C1074
634 Idle Air Control
3 Voltage Above Normal, Or Shorted To High Source P0509
4 Voltage Below Normal, Or Shorted To Low Source P0508
5 Current Below Normal Or Open Circuit P0505
7 Mechanical System Not Responding Or Out Of Adjustment P0519
13 Out Of Calibration P1300
636 Crankshaft Position Sensor
2 Plausibility Fault P0335
8 Abnormal Frequency Or Pulse Width Or Period P0336
637 Camshaft Position Sensor
7 Mechanical System Not Responding Or Out Of Adjustment P0016
8 Abnormal Frequency Or Pulse Width Or Period P0340
645 Tachometer Driver Circuit
3 Voltage Above Normal, Or Shorted To High Source P1739
GENERAL INFORMATION
