7.48
FINAL DRIVE
9. Inspect the shift yoke (H), shift lever (J), and shift lever
return spring (K).
10. Remove the set screw.
11. Remove the shift yoke pivot shaft (L) Use a 1/4 in.- 20
coarse thread bolt approximately 3 in. long to thread into
the pivot shaft.
12. Thread the bolt into the shift yoke pivot shaft (L).
13. Carefully pull the shift yoke pivot shaft (L) out of the carrier
cover.
14. Remove the shift lever (M) and springs (N) from the shift
yoke (H). Inspect the components for wear and replace as
needed.
H
J
K
L
L
M
N
H
