Polycom SoundPoint IP 560 User Manual

Customizing Your Phone
2 - 15
7. (Optional.) Change the Speed Dial Index.
It is automatically assigned to the next available index value.
Valid speed dial index values are from 1 to 9999. If you enter a speed dial
index that already, “Speed dial index already exists” appears. If you enter
an invalid value, “Speed dial index invalid” appears.
For more information, refer to Assigning Speed Dial Keys on page 3-22.
8. (Optional.) Change the Ring Type and Divert Contact.
These fields may be left blank.
For more information on setting the Ring Type field, refer to
Distinguishing Calls on page 2-21.
For more information on diverting contacts, refer to Diverting Calls on
page 2-23.
9. (Optional.) Change the Auto Reject, Auto Divert, Watch Buddy, and
Block Buddy.
Use and to switch between Enabled and Disabled settings.
For more information on setting the Auto Reject field, refer to Rejecting
Calls on page 2-22. For more information on setting the Watch Buddy and
Block Buddy fields, refer to Managing Buddies on page 4-6.
10. Press the Save or Cancel soft keys to accept or cancel changes.
11. Press to return to the idle display.
Adding Contacts From Call Lists
To add a contact to the local contact directory from a call list:
1. Do one of the following:
a Press , and then select Call Lists >Missed Calls,
Received Calls, or Placed Calls as desired.
b Press , , or to access the desired call list.

Polycom SoundPoint IP 560 Specifications

Display

display resolution	320 x 160 pixels
display type	backlit grayscale graphical LCD
LED backlight	custom intensity control

Power

power over ethernet	IEEE 802.3af
external power source	48V DC @ 380mA

Operating Environment

operating temperature	+10 to 40°C (+50 to 104°F)
operating relative humidity	20% to 85%, non-condensing
storage temperature	-40 to +70°C (-40 to +160°F)

Weight and Dimensions

dimensions	26.5 cm x 15 cm x 19 cm x 6.5 cm
phone weight	1.1 kg
unit box dimensions	12.5 in x 13.25 in x 3.5 in
unit box weight	1.8 kg
