Polycom SoundPoint IP 560 User Manual

Customizing Your Phone
2 - 25
Supporting Multiple Line Keys Per Line
Each line on the phone can be configured to have more than one Line Key
associated with it. This enhances call visualization and simplifies call
handling. If this is the case, the display could resemble the following figure:
Incoming calls to this line will be distributed evenly among the available Line
Keys. Similarly, outgoing calls will be distributed.
Your phone can be configured to have a combination of lines with a single Line
Key and lines with multiple Line Keys.
Supporting Shared Lines
Your for the SoundPoint IP 550/560 supports shared lines.
A shared line is indicated by a different line icon. In the following figure, the
lines 3161 and 3163 are private and the line 3166 is shared.
If two phones share a line, an incoming call to that number will cause both
phones to ring. The call can be answered on either phone but not both.
Calls on shared lines can be transferred, put on hold, or added to a conference.
Note
Shared lines are an optional feature and may not be supported on your particular
system. For more information, contact your system administrator.

Polycom SoundPoint IP 560 Specifications

Display

display resolution	320 x 160 pixels
display type	backlit grayscale graphical LCD
LED backlight	custom intensity control

Power

power over ethernet	IEEE 802.3af
external power source	48V DC @ 380mA

Operating Environment

operating temperature	+10 to 40°C (+50 to 104°F)
operating relative humidity	20% to 85%, non-condensing
storage temperature	-40 to +70°C (-40 to +160°F)

Weight and Dimensions

dimensions	26.5 cm x 15 cm x 19 cm x 6.5 cm
phone weight	1.1 kg
unit box dimensions	12.5 in x 13.25 in x 3.5 in
unit box weight	1.8 kg
