Polycom SoundPoint IP 560 User Manual

Using the Basic Features of Your Phone
3 - 19
Forwarding Calls
You can configure your phone so that all incoming calls are forwarded to
another party (refer to Static Forwarding). You can also forward calls while
your phone rings (refer to Dynamic Forwarding).
All incoming calls can be forwarded to another party while Do Not Disturb is
enabled on your phone. For more information, contact your system
administrator.
Static Forwarding
To forward all incoming calls to another party:
1. From the idle display, press the Forward soft key.
2. (Optional.) If multiple lines are configured on your phone, select the line
to forward from the list using and .
3. Using and , select the forwarding type you want to change,
and then press the Select soft key. The options are:
— Always—To forward all incoming calls
—No Answer—To forward unanswered incoming calls
—Busy—To forward calls that arrive when you are already in a call
4. Depending on your selection:
Note
Call Forwarding is not available on shared lines.
This feature is local to the phone, and may be overridden by call server settings.
For more information, contact your system administrator.

Polycom SoundPoint IP 560 Specifications

Display

display resolution	320 x 160 pixels
display type	backlit grayscale graphical LCD
LED backlight	custom intensity control

Power

power over ethernet	IEEE 802.3af
external power source	48V DC @ 380mA

Operating Environment

operating temperature	+10 to 40°C (+50 to 104°F)
operating relative humidity	20% to 85%, non-condensing
storage temperature	-40 to +70°C (-40 to +160°F)

Weight and Dimensions

dimensions	26.5 cm x 15 cm x 19 cm x 6.5 cm
phone weight	1.1 kg
unit box dimensions	12.5 in x 13.25 in x 3.5 in
unit box weight	1.8 kg
