48 MAN. PS 254 EN – Ind. 2
3.3.9. Saving, loading a program
! Saving a program on a memo card
Each program can be saved on a memo card,
16 programs per card is possible. The
procedure is described in the programming
manual. A brief summary is given below.
2 possibilities :
* Saving a single program
• Check that the key switch SY 26 is in the
position "Modification authorised".
• Insert the memo card.
• Choose the number of the program to be
saved with the switch BT 4 on the remote
control pendant.
• Press the transfer button to save the
information on the memo card
(symbol ).
• If the name of the program to be saved
already exists on the memo card, the
name of this program is displayed with a
question mark.
• If you validate the saving with the button
SY 23, the program which has been stored
on the memo card will be replaced by the
new one. The indicator corresponding to
the saving function will illuminate. Wait for
the indicator to extinguish before removing
the memo card.
• If the memo card is full, the error code !77
! is shown on the display SY 25.
* Saving several programs
• Check that the key switch SY 26 is in the
position "Modification authorised".
• Insert the memo card.
• Press the transfer button to save the
information on the memo card
(symbol ).
• Press the button « plus » (symbol ),
the characters 0 -> 15 ? are shown on the
display. The button «minus »
(symbol ) enables to come back to the
loading function of a single program.
• If you validate the saving with the button
SY 23, all the programs which are in the
memory of the power source
will be saved and the indicator corresponding
to the saving will illuminate. Wait for the
indicator to extinguish before removing the
memo card.
If, during the transfer, a fault is detected, the
operation is stopped and an error code is
shown on the display of the PS 254. Refer to
Appendix 3 and Chapter 8.5 for the error
codes and corrections to be made.
The program name is stored on the memo card
together with the program. However, the
number under which it is stored in the PS 254
is not saved. You can load the program under
a new number or in another power source. A
label on each card allows you to write manually
any information which you deem to be useful.
! Loading a program from a memo card
To load a program from a memo card, the
procedure is as follows:
*2 possibilities :
* Loading of a single program
• Insert the memo card.
• Choose the number you wish to give to the
program with the switch BT 4 on the
remote control pendant. This number
cannot already be attributed to another
program, but can correspond to a program
that you wish to replace.
• Press the button to load a program from
the memo card (symbol ).
• The first program stored on the memo
card is indicated on the display SY25.
• The keys SY 17 and SY 19 are used to
scroll up or down the programs.
• Validate the transfer by pressing . The
corresponding indicator will illuminate.
• Wait for the indicator to extinguish before
removing the card.
Warning If the program that is
registered in the card is not
compatible with the SY 30
selected range of current, it
will not be loaded up and !75!
error code is displayed on
the screen.
