68 MAN. PS 254 EN – Ind. 2
Error
code
Possible causes What to do
51 - No ground connection of the power source.
- Remote control pendant BP 1436 defect.
- Shielding of the cable of the remote control pendant BP 1436 defect.
- Card 217 00 634 defect.
- Correct.
- Check.
- Replace cable.
- Change.
52 - Phase failure of the mains input.
- Fuse S1 or S2 of the inverter unit defect.
- Remote control pendant BP 1436 defect.
- Card 217 00 633 or card 217 00 634 defect.
- Check and correct.
- Check and correct.
- Check.
- Change.
53 - Kurzzeitiger Netzspannungseinbruch.
- Karte 217 00 633 defect.
- Prüfen und Schweißstromquelle
erneut einschalten.
- Austauschen.
54
a) Closed welding heads of the MW, H or UHP type:
- Welding head is not in the home-position.
- Limit switch of the welding head defect or badly adjusted.
b) Welding heads of other types (without tacho):
- The pins D and E of the rotation motor cable are not short-circuited in
the plug connector.
c) All types of welding heads:
- Card 217 00 633 defect.
- Wrong reference number R30 for the identification of the welding
head programmed.
- Turn welding head in the home-
position.
- Check and change or correct.
- Correct.
- Change.
- Correct.
56 - Memo card upside down in the card reader.
- Flat cable for the connection between card 217 00 633 and card 217
00 634 defect or loose.
- Switch S1/1 on the card 217 00 634 in the wrong position.
- Watch for right position if you
introduce a memo card.
- Change or correct.
- Check and call for
maintenance.
60 - Printer defect
- 21700634 card defect
- Replace
- Change
62 - After the end of the last weld cycle, the power source has been
turned off and on again.
- The program number (YY) used for the weld cycle is different from
the program number (XX), which is actually chosen.
- Operate a new weld cycle.
- Choose program number YY
and restart printing of the weld
cycle report with the switch SY
28.
70 - Memo card is not introduced into the card reader SY 26.
- Memo card is not introduced correctly into the card reader SY 26.
- Introduce memo card.
- Remove the memo card and
introduce it correctly.
71 Memo card has been removed from the card reader before the end of
the storage.
Repeat storage (before removing
the memocard, wait until indicator
SY 13 becomes dark).
72 - The card 217 00 633 has been changed. - Choose with the switch BT 4 for
selecting the program number all
numbers from 0 to 15 one after
another.
73 - Any program stored on the memo card.
- Memo card introduced in the wrong way into the card reader SY 26.
- Use memo card with a program
stored on it.
- Remove card and introduce it
correctly into the card reader SY
26.
74 - Load from a memo card that has been removed from the card reader
before the end of the storage.
- Use a new memocard.
75
- The program stored on the memo card comes from a different tye of
power source.
- The position of the switch S3/1 or S3/4 on the card 217 00 633 is
wrong.
- - Use only programs made for a
power source PS 254.
- Set switches to the ""OPEN""
position.
