78 MAN. PS 254 EN – Ind. 2
Tubes to be welded Set-up before welding Range
Material Ø OD
Wall
thickness
Ø
electrode
Tip angle Nose
Distance
electrode
workpiece
mm mm mm degrés mm mm
Number
of built-in
program
Also valid
for MU III
welding
heads
PS 254
Stainless
25 1.2 2.4 30 0.2 1 17 * X
Stainless
25 2.5 2.4 30 0.2 1.2 18 * X
Stainless
26.9 3.6 2.4 30 0.2 1.2 19 * X
Stainless
38 1.2 2.4 30 0.2 1 20 * X
Stainless
40.5 0.4 2.4 20 0.1 0.6 21 * X
Stainless
48.7 2 2.4 30 0.2 1.2 22 * X
Stainless
51 1.2 2.4 30 0.2 1 23 * X
Stainless
51 1.8 2.4 30 0.2 1.2 24 * X
Stainless
63.5 0.7 2.4 20 0.2 0.9 25 * X
Stainless
63.5 1.5 2.4 30 0.2 1.2 26 * X
Stainless
88.9 1.6 2.4 30 0.2 1.2 27 * X
Stainless
88.9 2 2.4 30 0.2 1.4 28 * X
Stainless
88.9 3 2.4 30 0.2 1.6 29 * X
Stainless
114.3 3 2.4 30 0.2 1.6 30 * X
