ComPak
®
Series IOM
Factory charge for remote ACC option does not include refrigerant or oil charge
for either ACC or connecting refrigerant line between unit and ACC.
For ACC and lineset charging, see Table 4-2 and Table 4-3 in the Installation section.
NOTE
Factory Refrigerant Charge
Table 3-7. Factory Refrigerant R410A Charge
UNIT FACTORY CHARGE1 ( R410A)
AIR COOLED CONDENSER
(ACC)
WATER COOLED CONDENSER
(WCC)
MODEL
LBS OZ LBS OZ
0550 14 3 9 9
0800 15 5 10 7
1200 18 2 13 4
1400 24 13 17 9
1800 26 5 19 1
2600 36
1
25 15
35002 42 (81) 1 (0) 33 15
40002
44 (83) 1 (0) 35 15
1
Factory charge for remote ACC option does not include
refrigerant for either ACC or lineset.
2
Factory charge for RoofComPak® with Integral ACC in
parentheses.
