www.poolpak.com | 800-959-772556 | ComPak
®
Series - Installation, Operation and Maintenance
CPCS-PCP Service
Service Menu
To access the service menu:
• Press the PRG key to access the main menu.
• Use the arrow keys to scroll to the menu selection for Service and then press the Enter key.
• A password is required to access the service menu. Use the up and down arrow keys to set the
password to 0005. Press the enter key to accept.
Service menu navigation is similar to that described above for set point changes.
• Use the up and down arrow keys to select a sub-menu or parameter.
• Press Enter to accept the selection.
• To return to the previously selected parameter, press the Escape key.
• To completely exit the menu, press the Escape key repeatedly until the status screens are shown.
The following sub-menus are available in the service menu:
• I/O Configuration
• Digital Inputs
• Digital Outputs
• Analog Inputs
• Unit Configuration
• Installed Options
• Aux Air Heating
• Aux Water Heating
• Temperature Ctrl
• Humidity Control
• Water Temp Ctrl
• BAS Interface
• Multi-Unit Network
• Compressor
• Economizer
• History
• Manual Mode
• Demand Control
• Digital Outp Ctrl
• Utilities
• Units of Measure
• Passwords
Some service sub-menus above require an additional password. For these menus, use the
arrow keys and enter a password of 9995.
These instructions are for use by a qualified HVAC service technician only. Improper use
of the parameters in this menu will cause poor operation and possibly hazardous conditions.
I/O configuration parameters allow inputs and outputs to be forced to the selected state.
Improper use or settings will cause poor operation and possibly hazardous conditions.
! WARNING!
! WARNING!
