5.4 Sma Batte
5.4.1 Function
ATOM 2's sma batte is equipped with high-energy cells and utilizes an advanced batte management
system. Detailed information is as follows:
Basic Parameters
Cell Qty.
Rated Voltage
Charging Mode
2 series
7.7 V
USB-C/
Parallel Charging Hub
Batte Capacity
Charge Completion Voltage
Max. Charge Current
USB-C: 5 V/3 A
Parallel Charging Hub: 8 V/2.0 A x 3
2230 mAh
8.8 V
Balance
protection
Auto-discharging
protection
Overcharge
protection
Temperature
protection
Auto-limit of
charging current
Overdischarge
protection
Sho-circuit
protection
Batte health
monitoring
Communication
function
During charging, the voltages of the battey cells are automatically balanced.
After being fully charged, the batte will sta to auto-discharge to 50% ~ 70% of
the batte level when it's left idle for 5 days to protect the cells.
The batte stops charging automatically once fully charged.
Charging will stop automatically if the temperature of the batte is below 0℃
or above 45℃ to prevent damage.
The batte will restrict the charging current automatically if an excess current
is detected to protect the cells.
Discharging stops automatically to prevent excess discharge when the batte is
not in ight use. The batte will enter Hibernation mode and it's recommended
to charge the batte.
The power supply will be automatically cut if a sho-circuit is detected to protect
the drone and the batte.
The BMS will monitor the batte health, and prompt warnings if a damaged
batte cell is detected so you can replace the batte in time.
Information about charge cycles and remaining batte level is transmitted to the
drone and you can view it in the App.
12
Model: DSBT02B
