Power Meter Bulletin No. 3020IM9503R6/98
Appendix F—Register List December 1998
96 1998 Square D All Rights Reserved
Reg. No. ➀ Register Name Units Range Description
2018 Device Baud Rate Baud 1200, 2400, 4800,
9600, 19,200
2019 Phase Adjust In 100ths ±1000
User Correction
2020 Scale Group A: None –2 to 0 Scale Group A: Ammeter Per
Ammeter Per Phase –2=scale by 0.01
–1=scale by 0.10
0=scale by 1.00 (default)
2023 Scale Group D: None –1 to 2 Scale Group D: Voltmeter
Voltmeter –1=scale by 0.10
0=scale by 1.00 (default)
1=scale by 10.0
2=scale by 100
2024 Scale Group E: None –3 to 3 Scale Group E: kWattmeter,
kWattmeter, kVarmeter, kVA
kVarmeter, kVa –3=scale by 0.001
–2=scale by 0.01
–1=scale by 0.1
0=scale by 1.0 (default)
1=scale by 10
2=scale by 100
3=scale by 1000
2026 Scaling Error None 1 to 1F Possible Scaling Error
Bit 0 set if any other bits
are set
Bit 1 is set for possible phase
current scale error
Bit 2 unused
Bit 3 is set for possible phase
voltage scale error
Bit 4 is set for possible power
scale error
2027 Unused
2028 Command None 0 to +/–32,767 Command Password
Password (Computed by Power Meter)
2029 Master None 0 to 9998 Full Access Reset &
Password Setup Password
➀ These registers can be used with POWERLOGIC, Modbus, or Jbus protocols. Although POWERLOGIC
and Jbus protocols use a zero-based register addressing convention and Modbus uses a one-based
register addressing convention, the power meter, when configured for Modbus communications,
automatically compensates
for the Modbus offset of one. Regard all registers as holding registers where a
30,000 or 40,000 offset can be used (e.g., Current, Phase A = 31,003 or 41,003).
