Bulletin No. 3020IM9503R6/98 Power Meter

December 1998 Chapter 6—Communications

Figure 6-8: Terminating power meter with terminal block and MCT-485

In+

In–

Out+

Out–

Shield

In+

In–

Out+

Out–

Shield

Power Meter

(If Last Device in Daisychain)

Terminal Block

MCT-485

To Next Device on Daisychain

Belden 8723

RS-485

Terminals
