Power Meter Bulletin No. 3020IM9503R6/98
Chapter 4—Installation December 1998
14 1998 Square D All Rights Reserved
MOUNTING THE POWER METER
Power meter mounting options are described in this section.
Directly Behind the Display
To mount the power meter directly behind the display, follow these steps:
1. Turn off all power supplying the equipment before working on it. Follow
all safety precautions.
2. Mount the display. See Mounting the Display, page 12, for instructions.
3. Plug one end of the 1-foot communications cable provided with the
display into the display communications port (terminal 23, figure 4-1) on
the back of the display.
4. Hook the power meter mounting feet onto the top two display mounting
screws protruding from the back of the door or panel. Route the cable to
the right (hinged side) so it is not pinched between the power meter
module and the panel (figure 4-1).
HAZARD OF ELECTRIC SHOCK, BURN, OR EXPLOSION.
Only qualified electrical workers should install and wire this equipment.
Perform such work only after reading this complete set of instructions.
Failure to observe these precautions will result in death or severe
personal injury!
DANGER
!
!
CAUTION
HAZARD OF EQUIPMENT DAMAGE.
When mounting the power meter module, provide the following clearances
(from enclosure walls or other objects): terminal end: 4" (102 mm); vented
sides: 3" (76 mm). No clearance is necessary on the non-vented sides.
Failure to observe this precaution can result in equipment damage.
