Bulletin No. 3020IM9503R6/98 Power Meter
December 1998 Chapter 8—Metering Capabilities
1998 Square D All Rights Reserved 57
MIN/MAX VALUES (PM-650 ONLY)
The power meter stores the following minimum and maximum values in
nonvolatile memory:
• Frequency
• Current Phase A, B, C, and Neutral
• Voltage Phase A, Phase B, Phase C, A–B, B–C, C–A
• Power Factor Phase A, Phase B, Phase C, 3-Phase
• kW Phase A, Phase B, Phase C, 3-Phase Total
• kVAr Phase A, Phase B, Phase C, 3-Phase Total
CHAPTER 8—METERING CAPABILITIES
Table 8-1
Real-Time Readings
Real-Time Reading Reportable Range
Current
Per-Phase 0 to 32,767 A
Neutral ➀ 0 to 32,767 A
Voltage
Line-to-Line, Per-Phase 0 to 3,276,700 V
Line-to-Neutral, Per-Phase 0 to 3,276,700 V
Real Power
3-Phase Total 0 to +/- 3,276.70 MW
Per-Phase 0 to +/- 3,276.70 MW
Reactive Power
3-Phase Total 0 to +/- 3,276.70 MVAr
Per-Phase 0 to +/- 3,276.70 MVAr
Apparent Power
3-Phase Total 0 to 3,276.70 MVA
Per-Phase 0 to 3,276.70 MVA
Power Factor (True)
3-Phase Total –0.200 to 1.000 to +0.200
Per-Phase –0.200 to 1.000 to +0.200
Frequency
50/60 Hz 45.00 to 66.00 Hz
REAL-TIME READINGS
The power meter measures currents and voltages and reports rms values
for all three phases and a calculated neutral current
➀
. In addition, the power
meter calculates true power factor, real power, reactive power, and more.
Table 8-1 lists the real-time readings and their reportable ranges.
➀ PM-620 and PM-650.
