Power Meter Bulletin No. 3020IM9503R6/98
Chapter 4—Installation December 1998
18 1998 Square D All Rights Reserved
DIN Rail Mounting
To mount the power meter onto 35 mm DIN rail, follow these steps:
HAZARD OF ELECTRIC SHOCK, BURN, OR EXPLOSION.
Only qualified electrical workers should install and wire this equipment.
Perform such work only after reading this complete set of instructions.
Failure to observe these precautions will result in death or severe
personal injury!
DANGER
!
1. Turn off all power supplying the equipment before working on it. Follow
all safety precautions.
2. Mount a piece of 35 mm DIN rail in the desired location. Note: The DIN rail
must be horizontal. Position the power meter in front of and slightly above
the DIN rail (figure 4-4).
!
CAUTION
HAZARD OF EQUIPMENT DAMAGE.
When mounting the power meter module, provide the following clearances
(from enclosure walls or other objects): terminal end: 4" (102 mm); vented
sides: 3" (76 mm). No clearance is necessary on the non-vented sides.
Failure to observe this precaution can result in equipment damage.
3. Slip the two DIN rail hooks, located on the power meter case, onto the
upper edge of the rail.
4. Rotate the power meter down and press it against the 35 mm DIN rail
until the power meter snaps into place.
