Bulletin No. 3020IM9503R6/98 Power Meter

December 1998 Chapter 3—Hardware Description

The display connects to the power meter via the display cable. One display

communications port is located on the back of the display (figure 3-2, below).

The other display communications port is located on the meter connections

end of the power meter (figure 3-3).

Figure 3-2: Power meter display, front and back

Display Front

Display Back

Display

Communications

Port (Terminal 23)
