Power Meter Bulletin No. 3020IM9503R6/98
Appendix F—Register List December 1998
86 1998 Square D All Rights Reserved
Reg. No. ➀ Register Name Units Range
1208 ➁ Reserved
1209 ➁ Reserved
1210 ➁ Minimum Current Unbalance, Phase A Percent in 10ths 0 to ±1000
1211 ➁ Minimum Current Unbalance, Phase B Percent in 10ths 0 to ±1000
1212 ➁ Minimum Current Unbalance, Phase C Percent in 10ths 0 to ±1000
1213 ➁ Minimum Current Unbalance, Worst Percent in 10ths 0 to ±1000
1214 ➁ Minimum Voltage, Phase A to B Volts/Scale Factor D 0 to 32,767
1215 ➁ Minimum Voltage, Phase B to C Volts/Scale Factor D 0 to 32,767
1216 ➁ Minimum Voltage, Phase C to A Volts/Scale Factor D 0 to 32,767
1217 ➁ Reserved
1218 ➁ Minimum Voltage, Phase A Volts/Scale Factor D 0 to 32,767
1219 ➁ Minimum Voltage, Phase B Volts/Scale Factor D 0 to 32,767
1220 ➁ Minimum Voltage, Phase C Volts/Scale Factor D 0 to 32,767
1221 ➁ Reserved
1222 ➁ Minimum Voltage Unbalance, Phase A-B Percent in 10ths 0 to ±1000
1223 ➁ Minimum Voltage Unbalance, Ph. B-C Percent in 10ths 0 to ±1000
1224 ➁ Minimum Voltage Unbalance, Ph. C-A Percent in 10ths 0 to ±1000
1225 ➁ Minimum Volt. Unbalance, Worst L-L Percent in 10ths 0 to ±1000
1226 ➁ Minimum Voltage Unbalance, Ph. A Percent in 10ths 0 to ±1000
1227 ➁ Minimum Voltage Unbalance, Ph. B Percent in 10ths 0 to ±1000
1228 ➁ Minimum Voltage Unbalance, Ph. C Percent in 10ths 0 to ±1000
1229 ➁ Minimum Volt. Unbalance, Worst L-N Percent in 10ths 0 to ±1000
1230 ➁ Reserved
1231 ➁ Minimum True Power Factor, Phase A In 1000ths -100 to +1000 to +100
➀ These registers can be used with POWERLOGIC, Modbus, or Jbus protocols. Although POWERLOGIC
and Jbus protocols use a zero-based register addressing convention and Modbus uses a one-based
register addressing convention, the power meter, when configured for Modbus communications,
automatically compensates
for the Modbus offset of one. Regard all registers as holding registers where a
30,000 or 40,000 offset can be used (e.g., Current, Phase A = 31,003 or 41,003).
➁ PM-650 only.
